Description
The AT2032X Low Voltage Power Box is a high-capacity, stable low-voltage power supply device for large-scale industrial control systems, power distribution stations and commercial complexes. XBUS communication allows seamless connection with central control systems and peripherals, enabling remote power monitoring, data transmission and fault alarms. Its working voltage (AC 170V-260V/50Hz) adapts to regional grid fluctuations. Equipped with a 12Ah/12V lead-acid backup battery, it provides longer emergency power than AT2031X series to avoid production interruption. 2.5A function bus protection safeguards high-power equipment and complex circuits. Measuring 350mm×260mm×112mm, wall-mounted and compact for dedicated spaces, it adapts to (-10~+60)℃ and <95%RH environments. With three product types, it meets diverse needs, offering reliable power for high-demand electrical control systems.
Specification
| Communication Method | XBUS |
| Working Voltage | AC 170V - AC 260V / 50Hz |
| Backup Power | One Lead-acid battary 12Ah / 12V |
| Function Bus Protection Point | 2.5A |
| Product Dimensions | 350mm × 260mm × 112mm |
| Mounting Type | Wall |
| Working Enviorment | Temperature: (-10~+60)℃, Humidity: < 95%RH (no condensation), Pressure: (86~106)kPa |
| Product Types | Indoor type / Waterproof type / Explosion-proof type |
